Body Material: ABS
Size: 100*100*18mm (3.94″*3.94″*0.71″)
Filling: Epoxy+Quartz sand
Lens Material: PMMA
Raised Reflective Pavement Marker Features:
•Raised Reflective Pavement Marker water, oil, chemical, and heat resistance.
•Raised Reflective Pavement Marker can work more than 3 years normally.
•Very high reflectivity.
•Raised Reflective Pavement Marker easy installation with glues.
•Photometric values:exceeds 600(mcd/lux).
Raised Reflective Pavement Marker Parameters:
| Body material: | ABS |
| Filling: | Epoxy+Quartz Sand |
| Lens Material: | PMMA |
| Reflector type: | Double side/Single side |
| Quality: | ASTM D4280 & EN1463-1 standard |
| Size: | 100*100*18mm (3.94″*3.94″*0.71″) |
| Packing: | 56*22.5*22.2cm,100pcs/ctn (22.05″*8.86″*8.74″,100pcs/ctn) |
| Weight: | 180g/pc; 19kg/ctn (0.4bs/pc; 41.89bs/ctn) |
Installation Method Of Raised Reflective Pavement Marker:
1. Determine the installation location and distance, clean the road surface, and ensure that the Raised Pavement Markers are installed on a flat road surface.
2. Clean the bottom of the Reflective Pavement Marker and apply the epoxy glue evenly to the back of the studs.
3. Press the side with the glue on the road, fix the position, wait for the glue to dry.
4. Check within 2 hours of installation to ensure that all Reflective Pavement Markers are not installed incorrectly and are not bent or deformed due to compression.
5. Remove the installation isolation facility within 6-8 hours after the installation of the Raised Reflective Pavement Marker.
