Body Material: ABS
Size: 100*100*20mm (3.94″*3.94″*0.79″)
Filling: Epoxy+Quartz sand
Lens Material: PMMA
Raised Roadway Markers Features:
•Raised Roadway Markers water, oil, chemical, and heat resistance.
•Raised Roadway Markers can work more than 3 years normally.
•Very high reflectivity.
•Raised Roadway Markers easy installation with glues.
•Photometric values:exceeds 600(mcd/lux).
Raised Roadway Markers Parameters:
| Body material: | ABS |
| Filling: | Epoxy+Quartz Sand |
| Lens Material: | PMMA |
| Reflector type: | Double side/Single side |
| Quality: | ASTM D4280 & EN1463-1 standard |
| Size: | 100*100*20mm (3.94″*3.94″*0.79″) |
| Packing: | 56*22.5*22.2cm,100pcs/ctn (22.05″*8.86″*8.74″,100pcs/ctn) |
| Weight: | 250g/pc; 25kg/ctn (0.55bs/pc; 55.12bs/ctn) |
Installation Method Of Raised Roadway Markers:
1. Determine the installation location and distance, clean the road surface, and ensure that the Raised Roadway Markers are installed on a flat road surface.
2. Clean the bottom of the Raised Roadway Markers and apply the epoxy glue evenly to the back of the studs.
3. Press the side with the glue on the road, fix the position, wait for the glue to dry.
4. Check within 2 hours of installation to ensure that all Raised Roadway Markers are not installed incorrectly and are not bent or deformed due to compression.
5. Remove the installation isolation facility within 6-8 hours after the installation of the Raised Roadway Markers.
